Custom shop with small living quarters

From US$ 96,950.00

Live comfortably and pursue your passions! This functional single-story design provides ample space for both.

Relax in the cozy 1,200 sq ft living quarters, which feature two bedrooms. Step outside your door and enter your expansive 3,600 sq ft shop space, perfect for hobbies, small businesses, or inventory storage. This unique building offers a perfect blend of living and working space.

Finished in black and dark gray with color scheme with stone wainscot.

Dimensions: 60' (W) x 80' (L) x 12' (H)

Choose your own custom options for this home and get competing quotes from local suppliers.

Wall Color
Roof Color
Trim Color

Get Estimates3D Customize

SKU: BGLQ5003 Width: 60' Length: 80' Height: 12' Category:

* Price is for the shell only, varies by location & doesn't include foundation, installation, or interior walls

Metal building kit features

Start your project by customizing a base metal building kit package to create a structure that meets your live-work requirements, as well as your access, clearance, and interior storage space needs.

Customize the height, vertical roof style (and pitch), color, doors, and windows to create a unique building that reflects your chosen aesthetic.

  • What's Included

    Kit packages include:

    • Steel I-Beam framing
    • Steel roof & wall panels (26ga)
    • Complete trim package
    • Two framed door openings
    • Foundation anchor bolt plans
    • Engineer stamped plans
    • Building kit delivery
    • Installation instructions
    • All bolts, flashing & sealants

    Framing for Pre-Engineered Steel Building
    I-beam steel framing
  • Features

    Benefit from:

    • Bolt-up construction
    • Trussless roof design
    • Clearspan widths to 300'
    • Certified to 160 MPH wind
    • Certified to 110 PSF snow
    • 30+ year warranty
    • Fast, free delivery
    • Fast build & times

  • Customization

    Custom options:

    Doors - Choose overhead doors, rollup, sliding or bifold doors.

    Roof profile & pitch - Adjust the gable roof pitch or select a single-slope, gambrel, or monitor profile

    Insulation - Opt for vinyl-faced fiberglass, spray foam, or insulated metal panels (IMPs).

    Structural upgrades - Add porches, overhangs, a carport lean-to, or a mezzanine for loft storage.

  • Exclusions

    Items not included:

    • Permits
    • Foundation
    • Installation
    • Insulation
    • Interior build out

Get Four Quotes

Compare prices from local suppliers and save
Get Prices

Common Questions

  • Do I need a building permit?

    Yes, in most cases, especially within city limits. Some jurisdictions and properties on farmland can be exempt. Be sure to verify for your chosen job site.

    Some key points to consider:

    • First, ensure your plans comply with local zoning ordinances, then apply for a building permit. Larger buildings or those with more occupants face stricter regulations.
    • Submit certified plans: building officials require third-party certified plans for the structure and foundation. A reputable manufacturer should provide these.
    • Understand zoning: determine if your site is zoned commercial or residential and understand specific requirements.
    • Plan for permit processing: The permit application process can be lengthy.
    • Prepare an official site plan: a licensed surveyor or structural engineer should design an official site plan necessary for the permit applications.
    • Keep permits on-site: once you have the necessary permits, keep them at the job site ready for any required inspections.
    • Adhere to approved plans: inspectors will reference the certified blueprints throughout construction. If design changes occur, submit new certified plans and apply for new permits to avoid delays and fines.

  • Why must doors and windows be 2' from corners and the roof eave?

    Maintaining a 2-foot distance for doors and windows from the corners and the eave of a steel building's roofline ensures structural integrity, safety, compliance with building codes, and practical construction considerations.

    • Support and stability: corners provide critical support, and keeping framed openings away from corners guarantees stability.
    • Load distribution: a two-foot distance also ensures even load distribution, preventing structural issues.
    • Foundation stability: this prevents compromising the foundation and framing during high wind or snow loading.
    • Ease of construction: Simplifies the installation of doors and windows
    • Insulation and energy efficiency: the corner and eave areas are critical for the building's thermal envelope. Keeping openings away from these areas allows continuous insulation in these high-heat-loss areas. It also prevents thermal bridging at structural connections, improving the building's overall energy performance.
    • Weather protection: placing openings away from corners helps prevent water from seeping in and allows for sound flashing installation around openings, reducing exposure to wind-driven rain in vulnerable corner/eave areas.
    • Clearance for framing: a minimum 2-foot clearance allows room to frame and support the door or window opening correctly. This space is needed to fit wall girts between the corner column and door/window jamb.

    Our manufacturers often recommend adding 8-10 inches to the minimum 2-foot distance for buildings with bypass sidewalls to account for the bypass girt depth.

  • What are my options for installation?

    When it comes to erecting your building, you have three options.

    • Do-it-yourself (DIY). We only advise going this route on smaller buildings (under 2,000 square feet) and if you have previous construction experience.
    • Self-manage. With a self-managed project, you are responsible for hiring and managing the various sub-trades, including the concrete company for the foundation, the steel erectors to construct the kit, plumbers, electricians, etc.
    • Hire a General Contractor (GC). For a completely hands-off option, you may want to consider hiring a GC who will manage the entire project on your behalf, from pulling permits and installation to the final inspection. Expect to pay 10-20% for the services of a GC.

  • Why are your buildings more expensive than other options I have seen online?

    Our suppliers sell only commercial-grade, pre-engineered metal buildings (PEMBs) engineered with solid steel I-beam framing. The majority of buildings you will have seen online are light-gauge tubular metal buildings. The price difference is due to tubular structures weighing less than half of a PEMB, impacting the overall cost as steel is sold by weight. It’s a classic case of apples n’ oranges!

  • Can I finance a metal building?

    The simple answer is, sure you can. Here are the most common options when it comes to financing a new building.

    For smaller projects like garages or shops, consider home improvement loans that offer $1,000 to $50,000 with fixed interest rates. They’re easier to apply for, but they often have higher interest rates and less flexibility.

    On the other hand, a Home Equity Line of Credit (HELOC) or construction loan might be better for larger projects. HELOCs are more flexible and have competitive rates, but you will need to use your home as collateral.

    Construction loans are ideal for residential and commercial projects. These loans offer amounts ranging from $5,000 to $50,000.

    The final option available is farm credit.

    Unlike most banks and credit unions, institutions that offer to finance agricultural buildings are well-acquainted with metal buildings. Many fixed and variable-rate loans are available.

    Another route for agricultural buyers is the USDA’s “Farm Service Agency,” which offers loans and loan guarantees for farmers who aren’t eligible for commercial farm credit to help bridge the gap to commercial credit.
